Comparison Between AverMedia carrier boards for NVIDIA® Jetson Orin™ NX / Orin™ Nano modules

Introduction

In the realm of AI edge computing, AverMedia has emerged as a key player, offering a range of carrier boards tailored for NVIDIA's Jetson Orin™ NX and Orin™ Nano modules. Today, we delve into the specifications and features of three prominent offerings: the D133, D131, and D131L carrier boards. Join us as we dissect these boards to help you make an informed decision for your next AI project.

Jetson Orin NX Overview:

The Jetson Orin NX is a powerful system-on-module designed for AI edge computing. It features a highly efficient 12-core GPU, 6-core ARM CPU, and advanced AI processing capabilities. AVerMedia's carrier board for Jetson Orin NX is engineered to complement these features, providing a robust and flexible platform for various applications.

Connectivity: The carrier board is equipped with a variety of connectivity options, including USB 3.1, HDMI, Gigabit Ethernet, and more.
PCIe Gen4 support for high-speed data transfer.


Expansion Slots: Multiple PCIe slots allow for additional expansion, enabling the integration of custom peripherals and accelerators to meet specific project requirements.


Power Delivery: Robust power delivery system to ensure stable and efficient performance of the Orin™ NX module.


Camera Interface: Camera connectors for connecting multiple cameras, making it suitable for applications that require advanced vision capabilities.

Jetson Orin Nano Overview:

The Jetson Orin Nano is a compact and energy-efficient module, making it suitable for small form-factor applications with strict power constraints. It boasts a 12-core GPU, 2-core ARM CPU, and powerful AI capabilities. AVerMedia's carrier board for Jetson Orin Nano is tailored to harness the full potential of this module, offering a balance between size and functionality.

Form Factor: Compact design suitable for space-constrained applications.
Ideal for projects where size and power consumption are critical considerations.

I/O Ports: Limited but essential I/O ports, including USB, HDMI, and Ethernet, ensuring compatibility with various peripherals.

Power Efficiency: Emphasis on energy efficiency to cater to applications with strict power constraints.


Expansion Possibilities: Despite the compact size, the carrier board offers expansion options, allowing developers to add functionality as needed.

Comparison:

Performance Spectrum:

D133 targets high-performance applications demanding the capabilities of the Jetson Orin™ NX module.
D131 strikes a balance, suitable for a diverse range of projects with varying performance requirements.
D131L focuses on entry-level applications where space and cost efficiency are critical.

Connectivity and Expansion:

D133 offers extensive connectivity and PCIe slots for maximum customization.
D131 provides essential connectivity and PCIe expansion options for versatility.
D131L caters to compact solutions with limited I/O ports and efficient power delivery.



Technical Specifications Comparison

Model/Type  D133 carrier board D131 carrier board D131L carrier board
NVIDIA GPU SoC Module Compatibility/Jetson SoM Jetson Orin NX/ Orin Nano module Jetson Orin NX/ Orin Nano module Jetson Orin NX/ Orin Nano module
Networking 1 x GbE RJ-45
1 x M.2. key E 2230 for wifi		 1x GbE RJ-45 (PoE option)
1xM.2. key E 2230 for wifi 		 1x GbE RJ-45 (PoE option)
1xM.2. key E 2230 for wifi (AC9260)
Display Output 1 x HDMI output 3840 x 2160 at 60Hz for Orin NX, 30Hz for Orin Nano 1x HDMI  (3840 x 2160 at 60Hz) for Orin NX 1x HDMI (3840 x 2160 at 30Hz) for Orin Nano 1x HDMI  (3840 x 2160 at 60Hz) for Orin NX
1x HDMI (3840 x 2160 at 30Hz) for Orin Nano
Temperature Operating temperature -40°C~85°C (TBD)
Storage temperature -40°C ~ 85°C
Relative humidity 40 °C @ 95%, Non-Condensing		 Operating temperature 0°C~70°C
Storage temperature -40°C ~ 85°C
Relative humidity 40 °C @ 95%, Non-Condensing		 Operating temperature 0°C~70°C
Storage temperature -40°C ~ 85°C
Relative humidity 40 °C @ 95%, Non-Condensing
MIPI Camera Inputs(Internal) 2 x 4 lane MIPI CSI-2, 22 pin FPC 0.5mm Pitch 2x 2 lane MIPI CSI-2, 15 pin FPC 1mm Pitch Connector
1x 4 lane MIPI CSI-2, 36 pin FPC 0.5mm Pitch Connector		 2 x 2 lane, 1 x 4 lane MIPI
USB 1 x USB 2.0 type C for recovery
2 x USB 3.2 Type-A		 1 x USB 2.0 Micro-B, 4 x USB 3.2 Gen1 1 x USB 2.0 Micro-B, 4 x USB 3.2 Gen1
Storage 1x M.2. key M 2280 for NVMe 1x M.2. key M 2280 for SSD 1x M.2. key M 2280 for SSD
Expansion Header  20 pins: 2x I2C, 1x UART, 9x GPIOs 40-pin:  1x UART, 2x  SPI, 2x 12C, 1x I2S, 6x GPIOs
1xCAN (3-pin terminal block)
1xOOB supported by Allxon		 40-pin:  1x UART, 2x  SPI, 2x 12C, 1x I2S, 6x GPIOs
1x OOB supported by Allxon
Input Power 3.5mm Screw Terminal; 12V/5A, 9V~24V is recommended.

Voltage DC 9~24V

Current DC IN Jack on board: 7A~2.6A
ATX 4pin: 7A~2.6A

Voltage DC 9~24V

Current
DC IN Jack on board: 7A~2.6A
ATX 4pin: 7A~2.6A
Power Cord US/JP/EU/UK/TW/AU/CN (optional) US/JP/EU/UK/TW/CN/AU US/JP/EU/UK/TW/CN/AU
Thermal solution Fan solution (optional) Heat sink with fan(optional) Fan (optional)
Buttons Power and Recovery Power and Recovery Power and Recovery
RTC Battery Support RTC battery and Battery Life Monitoring by MCU Support RTC battery and Battery Life Monitoring by MCU Support RTC battery and Battery Life Monitoring by MCU
PCB/Electronics Mechanical Info W: 90mm x L: 76mm (TBD)
Weight: 70g (TBD)		 113mm (W) x 105mm (L) x 28.53mm (H)
Weight: 97 g		 113mm (W) x 105mm (L) x 28.53mm (H) Weight: 95 g
Certifications CE, FCC, KC(TBA) CE, FCC,KC CE, FCC,KC
Package 1x D133 Carrier board
DC IN jack cable
screws		 - -
BSP - - Applied to NVIDIA BSP directly
Product Link Link Link  Link



Conclusion:

The AverMedia D133, D131, and D131L carrier boards present a versatile trio, catering to diverse needs within the AI edge computing landscape. Whether you seek high-performance capabilities, a balanced solution, or a compact and cost-effective setup, AverMedia's carrier board lineup ensures there's a perfect fit for your NVIDIA Jetson Orin™ NX or Orin™ Nano-based project. Choose wisely and elevate your AI edge computing endeavors to new heights.
