AVerMedia Carrier Board D315 for NVIDIA® Jetson Orin™ AGX Modules

AVerMedia Carrier Board D315 for NVIDIA® Jetson Orin™ AGX Modules

Introduction

In the dynamic landscape of AI computing, the synergy between advanced hardware and software capabilities has become paramount for unleashing the true potential of autonomous machines. AVerMedia, a leading provider of cutting-edge solutions, introduces the Carrier Board D315 built with NVIDIA® Jetson AGX Orin™ module, heralding a new era of AI performance and power-efficient capability. Let's delve into the features, applications, and specifications of this innovative platform, poised to revolutionize industries worldwide.

Next-Level AI Performance:

The AVerMedia Carrier Board D315, powered by the NVIDIA® Jetson AGX Orin™ module, delivers unparalleled AI performance, enabling advanced analytics and handling a myriad of embedded IoT applications. With its exceptional compute capabilities and power efficiency, this platform sets new benchmarks for AI-driven solutions across various industries.

Versatile Connectivity Options:

Equipped with a 120-pin high-speed connector for MIPI SerDes cameras, the D315 Carrier Board fulfills the demand for Autonomous Mobile Robots (AMRs), facilitating rapid and flexible adjustments in the working process. Additionally, the inclusion of a 10G Ethernet port provides sufficient bandwidth for smart security applications, enabling simultaneous streaming from multiple IP cameras. Moreover, the connector for the 10GigE Vision Camera enhances smart inspection capabilities, ensuring fast and accurate detection for quality control in production.

Key Industries:

The flexibility and versatility of AVerMedia devices make them ideal for various verticals, including:

AMRs: AMR deployments benefit from live camera feeds, enabling rapid adjustments and significant productivity growth.

Smart Security: Leveraging live camera feeds, smart security systems enhance community safety through video analysis.

Smart Inspection: Live camera feeds empower smart inspection systems to deliver fast and accurate detection, improving quality control in production processes.



Technical Specifications

Feature AVerMedia Carrier Board D315
NVIDIA Jetson SOM NVIDIA® Jetson AGX Orin™ module (32GB or 64GB)
Networking 1x GbE RJ-45, 1x 10G RJ-45, 1x M.2 E key (Wi-Fi 6E)
Display Output 1x HDMI 2.0 (3840x2160 at 60Hz)
Temperature Operating: -25°C~85°C, Storage: -40°C ~ 85°C
USB 1x USB 2.0 Micro-B, 2x USB 2.0 Type-A, 2x USB 3.2 Type-A
Audio Intel HD Audio analog connector
Storage 1x micro-SD card slot
Expansion Header 40-pin, 1x M.2 Key M, 1x Micro SIM socket, 1x mPCIE, 1x PCIEx16, 1x CAN bus, 1x 120-pin, 1x OOB
Input Power DC in jack on board: 54V/2.78A adapter, ATX 4-pin: 1254V (10.82.4A)
Thermal Solution Fan (optional)
Buttons Power and Recovery
RTC Battery Supported RTC battery and battery life monitoring
Dimensions 141.5mm (W) x 133.5mm (L) x 29mm (H)
Weight 200g
Certifications CE, FCC, KC
Product Link  Link



Conclusion:

The AVerMedia Carrier Board D315, integrated with the NVIDIA® Jetson AGX Orin™ module, represents a paradigm shift in AI computing, offering unmatched performance, versatility, and scalability for a wide range of applications. With its robust features, versatile connectivity options, and certifications, the D315 Carrier Board is poised to drive innovation and accelerate the adoption of AI-driven solutions across industries. As we embrace the future of AI, AVerMedia remains committed to delivering cutting-edge technologies that empower organizations to thrive in an increasingly interconnected world.
