AVerMedia NX215 -Carrier Board NX215 for NVIDIA® Jetson Xavier™ NX/TX2 NX/Nano Version B01 Module

SKU
DB-AVM-0045
Brand Reward Points
0
₹17,999.00
Back Order
Topic: Topic

Product Description

AVerMedia’s NX215 Carrier board equips powerful NVIDIA® Jetson Xavier™ NX/TX2 NX/NANO modules. This efficient system-on-module (SoM) opens new worlds of embedded IoT applications with full analytic capabilities.

AVerAI NX215 is designed for the industry applications with spatial concern and feature a rich assortment of I/O ports for rapid AI-based solution development and seamless deployment as required by demanding business applications.

AVerMedia supports businesses of all sizes and offers customizable BSP services, flexible MoQ, in addition to NVIDIA’s JetPackTM SDK.



Technical Specifications

Model NX215
Type Carrier board
NVIDIA GPU SoC Module Compatibility

NVIDIA® Jetson Xavier™ NX/ TX2 NX/ NANO

Version V01 module

Networking

2x GbE RJ-45

1xM.2. key E 2230 for wifi (NANO don’t support)

Display Output

2x HDMI 2.0 (3840 x 2160 at 60Hz)

(NANO supports 1x HDMI 2.0 )

Temperature*

Operating temperature 0°C~70°C

Storage temperature -40°C ~ 85°C

Relative humidity 40 °C @ 95%, Non-Condensing

MIPI Camera Inputs (Internal)

•2x 2 lane MIPI CSI-2, 15 pin FPC 1mm Pitch Connector

(Compatible on NVIDIA® Jetson Xavier™ NX Developer Kit)

•1x 4 lane MIPI CSI-2, 36 pin FPC 0.5mm Pitch Connector

USB

1x USB 2.0 Micro-B for recovery

3x USB 3.0 Type-A

Storage

1x micro-SD card slot

1xM.2. key M 2280 for SSD

Expansion Header (Internal) 20 pins: 2x I2C, 1x UART, 4x GPIOs, 2xCAN (EU terminal block)
Input Power

DCINJACK on board & ATX 4pin

12V/5A, 12V~24V is recommended.

Power Cord US/JP/EU/UK/TW
Fan Module Heat sink with fan (optional)
Buttons Power and Recovery
RTC Battery Support RTC battery and Battery Life Monitoring by MCU
PCB/Electronics Mechanical Info

126mm (W) x 96mm (L)

Weight: 125 g

Certifications CE, FCC
Write Your Own Review
You're reviewing:AVerMedia NX215 -Carrier Board NX215 for NVIDIA® Jetson Xavier™ NX/TX2 NX/Nano Version B01 Module
  1. Power Connector x 1
  2. NX215 Carrier Board
