This is a simple-to-use Carbon Monoxide (CO) sensor, suitable for sensing CO concentrations in the air. The MQ-7 can detect CO-gas concentrations anywhere from 20 to 2000ppm. This sensor has a high sensitivity and fast response time. The sensor’s output is an analog resistance. The drive circuit is very simple; all you need to do is power the heater coil with 5V, add a load resistance, and connect the output to an ADC.
Model | MQ-7 |
---|---|
Power | 2.5V ~ 5.0V |
Dimension | 40.0mm * 21.0mm |
Mounting holes size | 2.0mm |
